SILVERLINER® OPEN STATE CAVITY BARRIER

SILVERLINER® OPEN STATE CAVITY BARRIER
SILVERLINER® OPEN STATE CAVITY BARRIER SILVERLINER® OPEN STATE CAVITY BARRIER SILVERLINER® OPEN STATE CAVITY BARRIER
Final price without VAT:
na dopyt

Choose a variant:

1000 x 75mm; max. air gap 50mm, max. void size between building and facade 50-500mm
1000 x 75mm; max. air gap 50mm, max. void size between building and facade 54-350mm
1000 x 120mm; max. air gap 25mm, max. void size between building and facade 52-527mm
1000 x 120mm; max. air gap 50mm, max. void size between building and facade 54-550mm
25000mm x 75mm, max. air gap 25mm, max. void size between building and facade 2-27mm
12500 mm x 75mm, max. air gap 50mm, max. void size between building and facade 4-54mm

Description:

The system developed to protect the voids between the outer façade and the inner construction element of the building. The product is designed for use in a ventilated façade, Silverliner® OSCB allows for 25mm or 50mm linear air gap to ensure movement of air and drain any moisture within the façade. The aluminium foil restricts fiber migration and offers a class ´0´ rating. In the event of a fire the intumescent outer edge of the product will expand and close the ventilation gap between the product and the façade preventing the passage of fire and smoke from one compartment to another.

Certification:

  • CE Marking
  • UL EU

Ordering ID:

In stock:

No

Intended areas of use:

  • Between the inner substrate and the external building envelope
  • In conjunction with Paraflam® where vertical cavity barriers are required
  • Where movement of air and moisture is required
  • Systems to cover void ranges from 2 mm to 550 mm

Key product advantages:

  • 3rd party approved - IFCC- IFCC 1672
  • Assumed working life of 25 years
  • Non-combustible core
  • ‘Dry fit’ solution, no time of curing
  • Fast installation using brackets
